TDS30/100 - Toroidal Choke 30H 100mA DC
Availability:
on sale
Dispatched within:
3 working days
Price:
Net price:
169,11 zł
product unavailable
add to wish list
* - Field mandatory
Rating:
4.99929
4.99929
Manufacturer:
Product code:
C23D-74903_20160314153309
Description
Toroidal choke 30H 100mA
Through the use of innovative toroidal cores production and winding technology, compared to EI-chokes, we have achieved exceptional electrical parameters. Major advantages are: minimal external magnetic leakage fields, noiseless operation and much lower DC resistance.
Technical data
| Core type | toroidal |
| Inductance L | 30H |
| DC Resistance | 66,5Ω |
| Nominal DC Current | 100mA |
| Nominal voltage | 400V |
| Dimensions | 88 mm (OD) x 61 mm (h), weight: 1,9 kg |
| Dimensions SUPREME | 120 mm (OD) x 80 mm (h), weight: 3,6 kg |
